Isolation Transformers · Single-Phase Control & Isolation
XH-1P-10KVA Single Phase Transformer 10kva 110v 220v. Single-phase control and isolation transformer designed for machine tools, industrial automation panels, and domestic/export equipment voltage matching.
| Product name | Three phase dry type isolation transformer |
|---|---|
| Voltage accuracy | ±1% |
| Voltage variation rate | ≤1.5 |
| Insulation resistance | ≥150M |
| Electrical strength | 3000VAC/1min |
| Design life | 20 years |
| Cooling mode | Dry air cooling |
| Input voltage | 660V 440V 380V 220V(Customizable voltage) |
| Temperature rise | ≤60℃ |
| Noise | 35db(Within meters) |
| Product name | Three phase dry type isolation transformer |
| Voltage accuracy | ±1% |
Status
Published
Product ID
XH-1P-10KVA
Last Updated
2026-07-31 09:31:37
High-precision 3D engineering cutaway model illustrating the core, windings, insulation, conservator tank, and protection accessories.
Watch routine factory testing and quality control inspections inside XinHuan's manufacturing facility.
All export transformers undergo 100% full routine tests (IEC 60076) before packing and shipping.
Official XinHuan factory 2D vector General Arrangement drawing for XH-1P-10KVA Single Phase Transformer 10kva 110v 220v. Includes front elevation view, top plan view, bushing center-to-center distances, mounting hole footprint, and complete vector group layout.
CE / ISO 9001 / IEC 61558
Plywood Export Crate Packaging, 10-15 Days Lead Time
