China Factory-Direct 13.2kV / 34.5kV Transformer Supplier for Colombia (60Hz / ANSI / RETIE)

🇨🇳 Direct Factory Export to Colombia. 15kVA-3000kVA 60Hz oil-immersed pad-mounted and pole-mounted transformers. Engineered for 13.2kV / 11.4kV / 34.5kV Colombian grids. B2B factory-direct shipping with 100% RETIE compliance support.

Request Colombia Quote WhatsApp Us Now
Factory-direct quotes from $1,800 USD 2-Hour Fast CIF Quote Export documents supported
11kV / 33kV
Voltage Class
50–3150kVA
Core Range
50Hz
Frequency
IEC 60076
Design Reference

Colombia Market Focus

Factory-Direct Oil-Immersed Distribution Supply

XinHuan is a China-based power transformer manufacturer exporting directly to Colombia via the Port of Buenaventura and Cartagena. We manufacture 60Hz oil-immersed distribution transformers and dry-type units engineered to comply with the Colombian RETIE (Reglamento Técnico de Instalaciones Eléctricas) safety standards and ANSI/IEEE grid requirements.

We supply 15kVA to 3000kVA transformers across Colombia's primary medium-voltage distribution ratings (13.2kV, 11.4kV, and 34.5kV) with 208V/120V or 240V/120V secondary outputs. Our factory specializes in heavy-duty pole-mounted units for rural grids and pad-mounted substations for urban development in Bogota, Cali, and Medellin.

Product Specification Table

Product Oil-Immersed Distribution Transformer
Voltage 11kV / 33kV
Capacity 50kVA–2500kVA
Frequency 50Hz
Phase Three phase
Cooling ONAN (Oil Natural Air Natural)
Insulation Class A Mineral Oil
Enclosure Hermetically Sealed Corrugated Tank
Standard IEC 60076 / ANSI C57.12.00
Vector group Dyn11 / Yyn0 / customized
Tap changer Off-circuit tap changer (±2×2.5%)
Winding Copper / aluminum
LV voltage 0.4kV / 0.415kV / customized
Installation Outdoor pad-mount / pole-mount / indoor

— VERIFIED QUALITY & COMPLIANCE

Certified B2B Manufacturing & Laboratory Performance

Every transformer, compact substation, and switchgear unit is engineered under audited ISO quality management systems and type-tested according to IEC 60076 and ANSI C57 international standards.

IAF / CNAS Accredited

ISO 9001:2015 Quality System

Certified Quality Management System covering design, coil winding, vacuum drying, oil filling, and routine testing of 10kV–35kV distribution transformers.

Environmental System

ISO 14001:2015 Environmental

Environmental Management System certifying low-loss eco-designed core assemblies, zero PCB insulation oil, and environmentally safe production controls.

Occupational Health

ISO 45001:2018 Safety System

Occupational Health and Safety Management System ensuring safety containment in high-voltage testing bays and factory assembly protocols.

CNAS Lab Type Tests

IEC 60076 & GB Type Tests

Complete routine and type test records (temperature rise, impulse voltage withstand, short-circuit withstand) conducted at CNAS-accredited national research institutes.

SGS Audited Supplier

SGS Verified Manufacturer Audit

On-site factory audit certificate by SGS / Made-in-China, verifying manufacturing premises, export capacity, assembly lines, and legal qualification.

≥180 Units/Yr Export

International Delivery Certificate

Verified annual supply performance and delivery certificate for overseas power grid EPC and industrial infrastructure projects (Mozambique, Nigeria, Kenya, SEA).

Local Market Notes

What Colombia Buyers Usually Care About

Colombia uses 60Hz frequency with common MV levels at 13.2kV, 11.4kV, and 34.5kV.

RETIE certification is a mandatory requirement for electrical installations.

Procurement Notes

Information That Speeds Up Approval

Verify the specific primary voltage (13.2kV vs 11.4kV) for the region.

Confirm if the unit requires pole-mounting brackets or a pad-mount enclosure.

Quote Checklist

What to Send First

Rated kVA capacity

Primary voltage (13.2kV/34.5kV) & LV output

Mounting type (Pole/Pad/Substation)

Target port (Buenaventura or Cartagena)

Engineering Submittal & Room Layout

Substation Room Fit & CAD Footprint Diagrams

Select your required kVA rating to inspect overall dimensions (L × W × H), wheel track gauge, net weight, and minimum electrical room clearance before submittal.

IEC 60076-11 Submittal Specs
XinHuan Dry-Type Core & Coil Technical Drawing
XinHuan Dry-Type IP20 Enclosure Technical Drawing
11kV / 33kV Dual Voltage
IEC 60076 / IEEE Compliant
100% Factory Test Passed
Humidity-Sealed Export Pack

1000 kVA Technical Dimensions

Class F / H Certified
Overall Length (L) 1,680 mm
Overall Width (W) 1,050 mm
Overall Height (H) 1,820 mm
Roller Wheel Track Gauge (D) 820 mm
Total Equipment Net Weight 3,650 kg
Min Substation Clearance 1,000 mm surrounding
Download Technical Data Sheet (PDF) Request Factory Engineering Submittal

Need customized voltage taps, dual primary windings, or IP23 enclosure specs? Submit your project specs for a custom data sheet within 2 hours.

Reference Visuals

Export Photos Buyers Can Compare Against

Transformer build for export comparison

ANSI/IEEE Export Reference

60Hz Distribution Transformer Build

Factory-built 60Hz ANSI-standard distribution unit for the Americas.

Tender & Approval Support

Common Information Procurement Teams Ask For

Routine test reports compliant with local requirements

CAD dimensional & layout drawings

Bill of Lading & customs clearance support

Tell us about any drawing, packing, or accessory requirements in the first RFQ. Detailed design drawings and final approval documents are scoped after commercial terms and project requirements are agreed.

Applications

Typical Colombia Project Applications

Emergency power grid rebuild and rapid deployment replacement transformers

13.2kV & 34.5kV regional utility distribution grid expansion

Pole-mounted rural electrification and single-phase/three-phase networks

Pad-mounted substations for commercial and residential developments

Direct B2B sea freight export taking advantage of efficient shipping routes

Delivery & Ports

Shipment Support for Colombia

Fast ocean freight shipping via direct routes to Buenaventura or Cartagena with complete customs submittals.

Direct shipments to major Colombian ports significantly accelerate project timelines for local EPC contractors and utility rebuild efforts.

Why XinHuan

Why Buyers Choose XinHuan for Colombia

Custom 60Hz ANSI/IEEE design matching Colombia's national electrical grid standards

Full support for RETIE certification compliance requirements

Extensive experience with 13.2kV, 11.4kV, and 34.5kV primary voltage classes

Fast production cycles for emergency grid replacement and rebuild operations

Project Fit

11kV / 33kV Distribution Range

Emergency utility rebuilds, 13.2kV distribution networks, and pad-mounted industrial sites.

Standard page scope: oil-immersed distribution transformers, 11kV / 33kV, 50kVA–1000kVA, three phase, 50Hz, ONAN cooling, copper/aluminum winding options, Dyn11 / Yyn0 / customized vector group, off-circuit tap changer, and outdoor or indoor installation.

Factory Capability, Shown Directly

See the Finished Transformer Area Behind Your RFQ

These are real photographs from XinHuan's Hefei facility. They show finished oil-immersed distribution transformers in the same manufacturing environment used for export projects.

Rows of completed oil-immersed distribution transformers in the XinHuan finished products workshop
Finished transformer workshop Real completed units, ready for final project checks
Completed oil-immersed transformers in XinHuan's marked finished products area
Finished products area Clear production-stage visibility for procurement teams
XinHuan vacuum drying equipment in the transformer production area
Production process Vacuum-drying equipment inside the working factory
Transformer oil handling area at XinHuan's Hefei factory
Oil treatment area Dedicated transformer-oil handling before dispatch
XinHuan transformer packing and shipping preparation
Export preparation Packing and loading preparation for project delivery
Need a closer look at build, packing, or inspection details? Send your voltage, kVA, quantity, and destination port with the RFQ.
IEC 60076 Routine Test & Assembly HD Factory Video

Factory Visual Proof

Visit the XinHuan Factory Before You Shortlist Suppliers

Explore our Hefei manufacturing facility through authentic production & routine testing videos. Practical visual proof for Colombia procurement teams evaluating a direct China manufacturer.

Hefei manufacturing base Automated coil winding & tank welding 100% IEC 60076 routine testing proof
Open Full Factory Tour & Videos
Official YouTube channels: Nancy Xu Serena XinHuan Transformer

Engineering Quality Assurance

Technical Standards & Certification Compliance

All XinHuan transformers undergo 100% factory routine testing, dielectric voltage withstand tests, and partial discharge inspection before dispatch.

IEC 60076 / 60076-11 ISO 9001:2015 Certified KEMA / CNAS Type Tested ANSI / IEEE C57

Engineering Submittal Package

Need CAD outline packs or type test reports for consultant approval in Colombia?

Request Technical CAD & Spec Pack

Related Internal Links

Continue by Product or Region

Use the nearest matching page for specifications, category browsing, or quotation follow-up.

Latin America Regional Guide

Explore 60Hz solutions across Latin America.

Request a Factory Quote

Submit project specs for a direct factory quote.

Colombia RFQ CTA

Send Your Transformer Requirement

Send your kVA rating, primary voltage (13.2kV / 34.5kV), mounting type (Pole/Pad), and target port (Buenaventura/Cartagena) for an immediate factory CIF quote.

Go to RFQ

FAQ

Frequently Asked Questions for Colombia

Do you supply 11kV and 33kV transformers for Colombia?

Yes, all transformers exported to Colombia are custom-built for 60Hz frequency and ANSI/IEEE grid compliance.

What capacity range is available?

We support the stringent technical and documentary requirements needed for Colombian RETIE certification.

Can the transformer be designed according to IEC 60076?

Standard medium-voltage ratings we supply to Colombia include 13.2kV, 11.4kV, and 34.5kV.

Can you quote FOB or CIF for Colombia?

Yes, we manufacture standard ANSI pole-mounted (15-167kVA) and pad-mounted transformers popular in Colombia.

What information is needed for a fast quotation?

We offer EXW, FOB, CFR, and CIF quotation options directly to Buenaventura or Cartagena ports.

Can XinHuan support EPC contractors, utilities, and industrial projects?

Fast-track manufacturing options are available for emergency utility rebuild and replacement projects.
