Integrated Hospital Operating Room Medical IT Power Cabinet

Turnkey integrated medical IT power system cabinet housing medical isolation transformer, insulation monitor, fault locator, transfer switch, and branch breakers in one IP30 stainless steel enclosure.

Request Quote Back to Catalog

Technical Specifications

Power Rating Range 3.15 kVA / 6.3 kVA / 8 kVA / 10 kVA
Input / Output Voltage AC 220V / AC 220V (Single Phase)
Enclosure Material 304 Stainless Steel / Cold Rolled Steel
Protection Degree IP30 / IP54 Indoor
Integrated Components Transformer + Monitor + Fault Locator + Remote Alarm
Standard IEC 60364-7-710, GB 50333

Product Information

Product ID

XH-MED-CAB

Last Updated

2026-07-30 07:38:34

Features

  • Pre-wired turnkey medical IT distribution panel reducing on-site installation time and wiring errors.
  • Integrated dual-power automatic transfer switch (ATS) ensuring seamless power switching in <50ms.
  • Acoustically insulated internal cabinet lining providing noise levels below 35 dB(A).

Internal Component Engineering Anatomy

High-precision 3D engineering cutaway model illustrating the core, windings, insulation, conservator tank, and protection accessories.

Dry-type transformer internal 3D cutaway model
High-Grade Silicon Core
Electrolytic Copper Windings
Tap Changer System
Buchholz & Temp Sensors

Factory Quality Inspection & Testing Video

Watch routine factory testing and quality control inspections inside XinHuan's manufacturing facility.

All export transformers undergo 100% full routine tests (IEC 60076) before packing and shipping.

Frequently Asked Questions

Specify kVA rating & feeder channels

IEC 60364-7-710, IEC 61557-9

Wooden case, 24m warranty
